| Subsystem | Transduce |
| Mid-Woofer | 2x12 inch cone |
| HF | 1x3 inch voice coil |
| Transduce | driver |
| Loanding | |
| Phase Aligred | |
| Horn-loaded | |
| Performance | 45Hz-18KHz (-10dB) |
| Frequency Range | 50Hz-17KHz (-3dB) |
| Nominal Beamwidth | |
| Horz | 60° |
| Vert | 60° |
| Sensitivity | 101dB (1W/1M) |
| 128dB (PEAK) | |
| Impedance(ohms) | 4 180Hz |
| Power | 900W (CONTINUUM) |
| 1800w (PEAK) | |
| Box Material | Birch Plywood |
| Exterior | Black Paint |
| Input Type | 1xNeutrik NL4 Speakon ±1 |
| Box Size | 510x470x1211(mm) |
| Weight(kg) | N.W: 60 G.W: 65.7 |
